Modern locomotive engineering, with questions and answers .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co · leaf 73
V^^in., D= I in. (which is also di-ameter of driven rivet).The strength of the unit strip of solid plate isPxTxT.S. =85,312. The strength of net section of plate after drilling isP — D X T X T.S. = 59,062. The shearingresistanceof tworivets is 2A x S= ;o,686. The crushingresistance ofrivets and… … Figure 21 THE BOILER 67 A double-riveted butt joint is illustrated by Fig. 21, and the dimensions are as follows: P, inner row of rivets = 2^ in. P, outer row of rivets = 51^ in, T of plate and butt straps = y\ in. D of hole and driven rivet = i in. Failure may occur in this joint in five distinct…
Locomotives
