Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 227
Fig. :iJ.—Thomsou-llouston dynamo. … Figs. 30. 3!.—Thomson Houston armature. the capacity of the machine, and, when all on, comi)lctes the form of the spheroidal arma-ture. The core is covered with several layers of insulating paper, and then is womid with in-sulated copper wire. To facilitate this winding, hard-wood pins PPare…
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
