Fio. 40.—Vulvcjccar. Via. -17.—Dash. Fin. IM.- (iovcrnor. Fui.s. 45-48.—Sioux City Corliss eiiKiiie—details. (not ov(!r) the valves, and that the exhaust-chamber is cast separate and independent from thecylinder, thereby preventing a cold, wet steam-jacket. The steam-valves are all made so as to… … Fig. 49.—Fishkill-Corliss eiigiue—cylinder. relieve themselves in case of water. Fig. 46 shows the hook-motion valve-gear, Fig. 47 thedash, and Fig. 48 the governor, which has light balls made to run at three times the speed ofthe engine, and a heavy sliding weight. The Fishkill-Corliss Engine.—A…
