Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 445
Fig. 30.—The Holmesknotter. … Fig. 21.—The Holmes knotter in position. The ejector is swung by a crank to which it is pivoted about midway of its length, the topbeing pivoted to a hinged guide-rod, thus causing the two tines of the ejector to execute the
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
