Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 503
her by a link. When either of the escutcheon-plugsis rotated, the cam Con the end of the plug will depress its dog-ging-lever and enter the corresponding talon, thus moving tlic boltwitliout regard to the position of the other dogging-lever. Thelatch-liolt (r is operated by the bell-crank /, whiili…
Mechanical engineering
