Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 275

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 275
e minutehand to XII. A latch. L. pivoted to the clock frame, is provided with apin, I, arranged to drop under the hook. H, carried by the lever. G. so as toprevent any action of the synchronizing levers except at the hour. Apin in a disk mounted on the cannon socket unlocks the latch. L.… … SECTION XVII. MINING DEVICES ANDAPPLIANCES. 271 Section XVII. MINING DEVICES AND APPLIANCES.

Mechanical movements
