Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 536
Fig. 6.—Vertical spindle miller. It can be readily attached to any standard locomotive cylinder. The frame or bed is fastenedto the steam-chest seat, and the uprights are moved on the frame by means of racks and … Fig. 7.—Vertical milling-machine. 512 MILLING-MACHINES.
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
