Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 580
e tongueand drivers seat are bolted to aseparate socket. Figs. 2 and 3,which also sustains the fulcrumof the lifter lever, a. The lifterchain, I, hangs slack while themachine is mowing. When thelever is slightly depressed by theoperator, it moves the lifter rod,c, upward, past the center onwhich… … Wood mowing inacliiue.
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
