vy is that it may act as a counterbalance for theother moving parts. In operation, the blank, which has previously been punched or trimmedto the desired size and shape, is placed over the die, and the blank-holder then first descendsin advance of the punch until it rests upon the blank, and exerts… … Fig. 6.—Toggle press. Elevation. 668 PRESSES, FORGING.
