team 100 lbs. and upward. Themarine boilers used in the United States gun-boats Yorktown, Concord, andBennington, have each three corrugated furnace-flues leading into one-Paynes boiler, common back connection. From here the products pass along throughthe nest of tubes to the chimney. The British… … Fig. 4.
