Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 79
Fig. 15.—Tlie Mostier boiler. 64 BOILERS, STEAM. … Fig. 16.—The Mosher boiler. the inner casing k. The lower ends of the tubes /* are marked 12, 13, in Fig. 16. The wallcomposed of the tubes/* extends the entire length of the furnace. The spaces between tlieinner and outer walls of tubes contain the tubes/, which are of the sinie general form asthe…
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
