An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 214
improved machines. The old style of doublestud has been dispensed with and simple trains of gears, shown inFig. Ill, have taken their places. The two intermediate gears, 60and 65, are connected by links with the gears on the drawing offroll shafts, and by this arrangement always remain correctly in… … 185 168 WOOLEN AND WORSTED SPINNING N represents the drawing off rolls; S, one of the small circies; and B^the large circle. Calculations. The total draft of the Noble comb can not becalculated accurately, and in fact, it is of little importance to knowthe draft, as the object of the machine is to…

Textile fabrics · Textile industry
