Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 840
Fig. 2. —Lash open-hearth furnace. Transverse section. … Vm. 3.—Lash opt-n-heanh furnace. Horizontal section on y, y. Fig. 2. way chamber (25), to which the flues {22-23) from each end of the furnaca converge, and towhich the air duct (26) delivers. This air duct (26) leads out from the ladle pit {27), andpasses directly under the hearth, in this way not…
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
