Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 856
hten or point wires or i-ods, or to straightenand render rods or shafts uniform in size. The main casting, B, is fittted with a steel ring,H, against which the rollers, R, bear. These rollers are mounted and turn on spindles, theends of which are cut down so as to fit in narrow slots cut in the… … Fig. ].—Tlie IJaytoii swaging machine.
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
