International Library of Technology · Scranton, International Textbook Co. · leaf 87
o the armature,and when an alternating current is sent through c an alter-nating magnetization is set up through the armature coils. 72 OPERATION OF 10 This induces an E. M. F. in each coil; and if any short cir-cuits exist, such heavy local currents are set up that theshort-circuited coils soon… … Fig. 29. method of testing for such faults. To cut out a short-cir-cuited coil, temporarily disconnect its ends from the commu-tator and bend back the ends out of the way and tape themso that they cannot touch each other and put a short pieceof wire, or jumper, in place of the coil so…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 87](https://img.insideoutlibrary.com/img/1024/ia-electricengineer04inte-87-27.webp)
