Modern painting, hardwood finishing and sign writing .. (1914)
Armstrong, George D. [from old catalog], Hodgson, Frederick Thomas, 1836- [from old catalog], Delamotte, Frances George. [from old catalog], Maire, Frederick. [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. expressly for Sears, Roebuck & company · leaf 490
^in., or more than 234^in., from center to center;for hard wood, or for small work in thin wood, theyshould be spaced closer still. In setting out the pins, or rather the mortises inwhich the pins have to fit, a half dovetail should beplaced at both top and bottom, as shown in Fig. lO,and the… … Fig. 10 strength, then tails of the shape shown in Fig. 11,should be used. The bevels of the tails should be as shown in thedrawings, and in no case should they be shaped as atM, Fig. 14. Ifmade like that,there would begreat danger ofthe sides split-ting off at E,and althoughthis shape atfirst…
Painting, Industrial · Wood finishing · Lettering
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
