The American house carpenter: a treatise upon architecture, cornices and mouldings, framing, doors, windows and stairs. Together with the most important principles of practical geometry (1852)
Hatfield, R. G. (Robert Griffith), 1815-1879 · New York, J. Wiley · leaf 278
Fig. 316. Fig. 315. 262 AMERICAN HOTjSE-CARPENTEU. 414.—To find the shadow of a shelf having its front edge^ orendy curved on the plan. In Fig. 315 and 316, A and A show anexample of each kind. From several points, as a, a, in the plan,and from the corresponding points, o, o, in the elevation,…
Carpentry · Architecture
