M. Vitrvvivs per Iocvndvm solito castigatior factvs cvm figvris et tabvla vt iam legi et intelligi possit (1511)
Vitruvius Pollio · Impressum Venetiis ... : Sumptu miraq[ue] diligentia Ioannis de Tridino alias Tacuino · leaf 209
umhominibus calcantibus verfatur,& hauriendo aquam per aperturas,qua? funt 1 frotibus tympani,reddit eam per columbaria fecundum axem, ita fuppofitolabro ligneo habente vna fecum coniunclum canalem,& hortis ad irrigan<lum,& falinis ad temperandum p rsebetur aqua: multitudo» N iii… … Cum autem altius extollendum erit,eadem ratio comutabitur fic* Ro/ta fiet circum axem eadem magnitudine ut ad altitudine qua opus fue/rit conuenire polTit,Circum extremum latus rota?figetur modioli quadrati pice &cera folidatijtacumrotaacalcantibus uerfabitur, modio/li pl:ni ad fummum…
