e-scribe the hand-mill represented in Fig. 132. 282. What are Bevel-wheels What 124 MECHANICS. form any other angle withtheir axes than a right angle. A pair of bevel-wheelsin gear are shown in Fig.133. 283. Rack and Pin-ion.—Circular motion isconverted into rectilinear(that is, motion in a… … 284. Forge-Hammer.—A toothed Fig. 135. BACK AJS1> P1MON. wheel may produce an alternate up-and-down motion, as in the case of the Forge-hammer, represented in Fig. 135. The wheel is so placed that its teeth successivelycome in contact with the handle of the hammer, whichturns on a pivot. As the…
