Naval architecture: a manual on laying-off iron, steel, and composite vessels (1898)
Watson, Thomas Henry · London; New York: Longmans, Green and co., [etc.] · leaf 180
74 NAVAL ARCHITECTURE. CHAPTER VIII. Principal Moulds, and the order they are sent into the Yard—Stem—SternFrame—Shaft Struts—Stern Tubes—Flat Plate Keel—Centre throughPlate Keelson—Boat Beams. MOULDS. Wood moulds, or templates, are made in the loft of various partsof the vessel for the use of the…
Naval architecture -- Handbooks, manuals, etc · Naval architecture · Ships, Iron and steel
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
