llowance for Beam Knees or Arms.—TheClassification Registry rules require that the depth of beam kneesshould be twice and a half the depth of the beam web, and once anda half the depth across the throat. For special reasons it is some-times more. Knees to tee beams are best formed by sawing up… … 90 NAVAL ARCHITECTURE. width of the deck plan. In Fig. 82 the tee beam knee is shown inposition. Girth the centre line a b of the turned down part, and setit out straight c/1 &, then c d is the extra allowance for one side of theship, which works out in practice about the depth of the beam…
