Mechanical equipment of buildings; a reference book for engineers and architects (1916)
Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 274
n rod, 2 j^ inches. Area of piston rod, 4.66 sq. in. Net area of piston, crank end, 172.05 sq. in. Head End Crank End Average ordinate length 1. 0772 1. 0772 Multiply by scale of card 50 50 Mean effective pressure 53. 86 53. 86 Pe L A N Crankend 53.86X1.667X172.05X150 33,000Pe L A N Headend 53.86 X… … ■s P ;3o ■sssjj leiyui sq/ oOh■ss9Jd J9/!og -sqi iQl- 252 POWER PLANTS AND REFRIGERATION POWER DEVELOPED BY RECIPROCATING ENGINES Thepower developed by an engine is expressed in terms of either brake horsepower (d.hp.)or indicated horsepower (i.hp.) usually the latter. Brake Horsepower. The brake…
Building · Heating · Ventilation
