Naval architecture: a manual on laying-off iron, steel, and composite vessels (1898)
Watson, Thomas Henry · London; New York: Longmans, Green and co., [etc.] · leaf 265
FIG. 117. … ARMOUR. 117 •J and transverse bulkheads, are indicated before arranging the plateedges; which are made parallel to the centre line over the horizontalportion, and about parallel to the ships side on the slope. Theedges must be straight between the butts. It will be evident thatsome allowance in…
Naval architecture -- Handbooks, manuals, etc · Naval architecture · Ships, Iron and steel
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
