from R S, on each section, and set-off inthe expansion below R1 R2. The termination may be got by lifting-cutting point at W square to R S, and measuring it off parallel toRXR2 to cut line R\ X, R2, by which you get W1 and W2. Drawcurve W1 S1 W2 through points, and you have the line on the…
