Naval architecture: a manual on laying-off iron, steel, and composite vessels (1898)
Watson, Thomas Henry · London; New York: Longmans, Green and co., [etc.] · leaf 378
The boundary line, or fore edge of rabbet, is A. The middle line of rabbet is B. The bearding line, or after edge of rabbet, is C 95 9* 95 » nrNaval architecture -- Handbooks, manuals, etc · Naval architecture · Ships, Iron and steel
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
