next the transomwhich is made slightly fuller to form a fair line with the other partof the vessel. When faired the corrected points are projected into Note.—In future reference the word Profile will be dropped, and Sheerused when referring to it, which is the common term. LAYFNTG-OFF THE SHEER… … knuckle side sheers, above and below the level hueL M, and placing them on their corresponding linesin the Body, through which curves are drawn. The deck line may be put in, in the samemanner, by drawing in the centre, and findingthe camber in the usual way. The part belowthe knuckle line is faired…
