The naval constructor: a vade mecum of ship design for students, naval architects, shipbuilders and owners, marine superintendents, engineers and draughtsmen (1904)
Simpson, George, 1865- · New York, D. Van Nostrand company ; London, K. Paul, Trench, Trübner & co., ltd. · leaf 315
ssary to increase the strength of the beams at the endsof hatchways by adding to their sectional area — but not to theirdepth if avoidable. The beams supporting bridge or shade decks fitted over housesand extending to ships side are frequently carried thwartship inone bar, the casings being scored… … SPLIT HERE Fig. 171. Hold Pillars 301 HOLD PILLARS. Support is given the beams on the various decks by stanchions.Various sections are employed for this purpose, as round bar, pipe,/ section and columns built of channel <>r plate and angle bar.F<>r vessels carrying general cargoes, ibe…
Shipbuilding · Marine engineering
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
