A new manual of perspective: containing remarks on the theory of the art, and its practical application in the procudtion of drawings ... Illustrated by numerous engravings (1849)
Whittock, Nathaniel · London, A. Hall & Co. · leaf 43
. From the ends of the shortlines, where they intersect the lines b d runningto a, draw lines to the point of distance J, andas many diamond-shaped stones may be formedas the space will admit. 40 MANUAL OF PERSPECTIVE. Operation 4. — A pavement of squares inperspective. The student may suppose he… … the latter, place the point of sight; then markpoints of distance in their proper places on thehorizontal line, at an equal distance from the MANUAL OF PERSPECTIVE. 41 point of sight; then proceed to set off the sizeof one end of a square block on the base line,immediately opposite the point of…
Perspective
Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
