Notes and examples in mechanics; with an appendix on the graphical statics of mechanism; (1903)
Church, Irving P. (Irving Porter), 1851-1931 · New York, J. Wiley & sons; [etc., etc.] · leaf 200
Am. Bk. Note Co. N. T. CONTENTS. Assumptions 1 Efficiency 2, 3 Overhauling =., 3, 4 Sliding Friction 4 Mill Elevator 5 Wedge 6 Jack-screw 7 Pivot and Journal Friction 9 Bell-crank... ^ 9 Slider-crank 10 Beam-engine 11 Oscillating Engine 13 Ore-crusher 14 Rolling Friction 15 Crane (rollers of) 17… … Am. Bk. Note Co. N. Y. PLATE II. Figures 5 to 8 k BELL-CRANKMechanics, Applied · Engineering · Graphic statics
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
