n is L shaped. It is specified on a drawing as an L.Apex of a Truss.—This is the highest point, as Y in the Roof Truss, Fig, 19. Batten, Stay or Tie Plate.—A plate used at the ends of compression members to hold the two segments to-gether. See Latticing, Fig. 20.Bevel.—^The inclination of members… … J - <\l CSJ <\J <\J Fig. 20. 64 Clevis.—A forked piece with a threaded hole at one end, used for connecting a pin plate to a tie rod. See Fig. 20.Clip or Clip Angle.—A short angle used for connecting two pieces. In Clip Angles, Fig. 20, a clip is used at A to provide enough rivets to…
