tion ABis a view from foundation to roof through theporch including both inside porch wall and out- side living room wall, section CD, a bedroomoutside wall. Cottage construction use does notneed to be very tight. Cedar posts are the ac-cepted foundation material. Drop siding is usedalone without… … PLATE 85—WOODEN ROOF TRUSS WITH DETAILS OF JOINTS A strong truss, giving a greater height in the oughly spiked together and bolted at the joints center of a building than the ordinary truss with as shown. The constructive details are typical of horizontal lower chord. The upper and lower many forms…
