Notes on technical sketching and free hand lettering for engineering students (1912)
Smith, Alton Lincoln, 1867- [from old catalog] · Worcester, Mass., The author · leaf 108
, Hood Q, Hood R. Lathe Center B, Fig. 8.—Countersunk head Rivet, Fig. 10.—Countersunk head Cap Screw, Tab. 3.—Box B, Fig. 8.—Pan head Rivet, Fig. 10.—Blanks for Bevel Gears, Fig. 18.—Reducing Coupling B,Fig. 11.—Washer H, Fig. 48.—Boiler Patch Bolt L, Fig. 48.—Taper Shank, Tab. 13. 13. Sphere… … Fig. 48 106 14. Torus Ring Forms.—Torus Ring M, Fig. 47, lying flat.—Valve Handle T, Fig. 48.—MachineHand Wheel, Tab. 8.—Eye Bolt, Tab. 10.—From Fig. 11 (See Section 251) Return Bend J. Elbows,Q. T, and X. 15. Miscellaneous Forms.—Cast Washer, Tab. 10.—Machine Handle, Tab. 9.—Latch HandleA, Fig. 8.…Mechanical drawing · Lettering
