Practical mechanical drawing and machine design self taught .. (1907)
Westinghouse, Charles. [from old catalog] · Chicago, F. J. Drake & co. · leaf 94
rig. 175—Details of Surface Gauge. Instead of drawing the parts of the pipe on thetwo sides of the plug in the same straight line asin Fig. 170, one may he shown proceeding fromthe bottom of the casing, so that the fluid willhave to pass through the bottom of the plug andthrough one side. This is a… … Fig. 176—Details of Surface Gauge. one of these views a few of the principal dimen-sions are marked. The details, fully dimensioned,are shown separately in Figs. 172 and 173, Explain clearly how the center is moved back-wards and forwards, and also how the spindle con- 92 MECHANICAL DRAWING taining…
Mechanical drawing · Machine design
