f<P^22 … Fig 17 50 RACK FIG. 18 141. A rack is essentially a Spur Gear with an infinite diameter. Give its length and width, thekind and pitch of teeth. BEVEL GEARS FIG. 18 142. In bevel gears the pitch surfaces are cones. In the drawing they are shown as isoscelestriangles DAB and DBG. The pitch circle on…
