Rollins, William Herbert, 1852-1929 · Boston : The University Press · leaf 512
Vd NOTE 65 —FIGURE 60 —DIAGRAM SHOWING . THE PLAN ON WHICH THE TUBE SHOWN IN FIGURE 58, PLATE 28, IS CONSTRUCTED Plate 31 … NOTE 69 —FIGURE 62 —AN X-LIGHT TUBEIN WHICH THE CENTRAL CATHODE RAYSTRIKES THE TARGET NORMAL TO ITS SUR-FACE. THE TARGET IS PROVIDED WITH ASLIT TO SHOW THE SPREADING OF THEBEAM OF X-LIGHT PASSING THROUGH IT Plate 32
X-rays · Phototherapy
