-lined with zinc-, with anaperture ET in the side, is attached, through which the con-centrated X-light escapes to the part of the body to betreated. A number of ends of different sizes and shapes arerequired. The quality of the X-light is regulated by turn-ing the handle RHH. The movements… … NOTE 156 —FIGURE 4 —A NON-RADIABLEX-LIGHT TUBE BOX WITH AN X-LIGHT CON-CENTRATOR ARRANGED FOR TREATINGDISEASES OF THE MOUTH The figure shows an X-light concentrator in position fortreating a disease of the mouth. The end ET of non-radi-able material is placed in the mouth against the diseasedarea.…
