A manual of naval architecture. For the use of officers of the Royal Navy, officers of the Mercantile Marine, shipbuilders, shipowners, and yachtsmen (1889)

White, W. H. (William Henry), Sir, 1845-1913 · London, J. Murray · leaf 353

An illustration from A manual of naval architecture. For the use of officers of the Royal Navy, officers of the Mercantile Marine, shipbuilders, shipowners, and yachtsmen, 1889, leaf 353 — dth ah throughout the depth of the beam, before it was bent.For any layer in the beam the elongation or compression pro-duced by the bending varies directly as the distance of thatlayer from the neutral surface. Within the limits of elasticityof the material, the elongation or compression also… … Section

Naval architecture

Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
