On yacht sailing : a simple treatise for beginners upon the art of handling small yachts and boats (1904)
Day, Thomas Fleming, 1861-1927 · New York : Rudder Pub. Co. · leaf 97
in mast and doublings. 14— Fore boom. 15— gaff- 16— Main boom. 17— gaff 18— Fore sheet. 19— peak halyards. 20— throat 21— peak halyard bridles.. 22— Main sheet. 23— peak halyards. 24— throat 25— peak halyard bridles. 26— Fore topping lift.27_Main 28— Preventer backstay or runner. 29— Topmast… … 95 SAIL PLAN OF SCHOONER. 1— Mainsail. 9— peak. 10— throat. 11— tack. 12— clew. 2— Fore sail.I3_ peak. 14— tack. 15— clew. 3— Fore staysail.:6— head. 17— tack. 18— clew. 4— Jib- 19— head. 20— tack. 21— clew. 5— Jib topsail. 22— head. 23— Jib topsail tack. 24— clew. 6— Main topsail. 25— head. 26—…Yachts · Yachting
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
