hand-wheel at theside of the machine 1)eing nsed for this; with the fenceon the movable section. In cntting stock to length, the miter cnt-off gage, Fig.162, is nsed. This gage has a groove into which may befixed a stop rod,either 18 or 36 inlength. The machineis set np as pre-V i o n s 1 y… … Fig. 162. Miter Cut-Off Gage.
