Pattern making and foundry practice; a plain statement of the methods of wood pattern making, as practiced in modern pattern shops, with complete instructions for sweep work and notes on foundry practice, together with numerous drawings taken from actual patterns .. (1905)

Hand, L. H. (Louis Henry), b. 1854 · Chicago, F. J. Drake & co. · leaf 66

An illustration from Pattern making and foundry practice; a plain statement of the methods of wood pattern making, as practiced in modern pattern shops, with complete instructions for sweep work and notes on foundry practice, together with numerous drawings taken from actual patterns .., 1905, leaf 66
s puttied upand the piece shellacked and used for a patternfor other pockets. This method, however, wasonly resorted to when it was necessary to get carsready for service on very short notice. Theusual custom and the proper method is to castthis pattern with a core. The procedure for thisis as…

Patternmaking · Founding
