Pattern making and foundry practice; a plain statement of the methods of wood pattern making, as practiced in modern pattern shops, with complete instructions for sweep work and notes on foundry practice, together with numerous drawings taken from actual patterns .. (1905)

Hand, L. H. (Louis Henry), b. 1854 · Chicago, F. J. Drake & co. · leaf 73

An illustration from Pattern making and foundry practice; a plain statement of the methods of wood pattern making, as practiced in modern pattern shops, with complete instructions for sweep work and notes on foundry practice, together with numerous drawings taken from actual patterns .., 1905, leaf 73
7^7^ J30 68 PATTERN MAKING half circular portion of the pattern c, Fig. 31.The only difficulty to be met with in makingthis pattern is the miter joint ^, which isfound by the intersection of parallel lines of equaldistance from each other on the straight side,with similar circular lines struck from… … Ti^ 31 of the circular portion of the work. This is thecommon rule for mitering straight and curvedmouldings. Or the joint can be coped together,the circular part of the core box can be turnedinto the face of a plank of suitable size, which,when cut across the line of its diameter, formsthe…

Patternmaking · Founding
