ws a trussed lintel which is claimed to becheaper than structural steel and more effective. Fig. 8 shows a common way of extendingreinforcing rods over a support in case of con-tinuous floor construction. The top rods takethe tension over the supports when the floortends to deflect or bend in… … HoZe =4 j^ B Fig. 9. Clamp for Beam or Small Column Form. This clamps around the corners of the forms,and, when in place, is set up tight by hitting onfree end of bar. Plate 2 shows a form of shaft-hanger insert. CEMENT CONSTEUCTION 13 These are attached to the forms during the con-crete…
