Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 103
Fig. 161. Segmental Con-struction of Web forSheave Pattern … Fig 162. Web with Rim Glued On 7M Fig. 163. Construction Views of SheavePattern
Patternmaking
