Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)
Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 142
--Loose Flange … Fig. 223. Interchangeable Flanges on Pipe Pattern Flanges are often fastened to the pipe pattern by screws only,so that flanges of different diameter can be attached, Fig. 223. Stock. The flanges should be made by gluing up three piecesand crossing the grain of the pieces so that the grain of each…
Patternmaking
