Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)

Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 205

An illustration from Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice, 1916, leaf 205
Thii side to be mcd9in the nowel mold. Fig. 314. Diagram of Stripping Plate. One End Broken to Show Holes throughWhich Pattern Is Drawn Co/Je core print. The pattern parts onthis line. … Fig. 315. Pattern for Stripping Plate Plate Pattern. The plate is made of narrow strips of stock,glued so as to reverse the heart side of adjoining pieces. It willnot be necessary to spline these patterns, for only one casting is PATTERN MAKING 187 usually required and the pattern is generally…

Patternmaking
