Fig. 289. Partially Completed Stock for Cap Pattern produce a layout showing the height or thickness of the pattern,as illustrated by the line i: Forming, The semicircular hole is cut out with a core-boxplane, to a diameter of t, which is larger than the shaft, as this is … . Wood screws Fig. 290. Cap Pattern Stock Mounted on Wood Arbor Ready to Turn Outside •a babbitted bearing. Band saw to the line i, leaving stock at jjso that when band sawing to the lines h h the top surface or workingface of the stock will be kept parallel to the table. The stock atj may be cut…
