L parallel toAK; join E RMP and E LMP, and produce them backwardsto meet B.L. in Z and X. Mark off XC = 4, also ZD = 4 :join D RMP and C LMP, also L R V.P. and L L V.P.-through F draw FM, and through G draw GH, parallel toEL; join M L V.P. and H R V.P. to meet at X, completingthe required cube. For… … MISCELLANEOUS EXERCISES. 101 Exercise XV.—Figures in Angular Perspective.(In the following consider H = 6, L.D. = 4, scale \ = 1.) 1. A square whose sides are 4, lies on ground; an angletouches P.P. 2 to right; angle 45°. 2. Draw same, 3 to left and 2 within P.P.; right side makesangle of 60c. 3.…
