and MAN; set off BO and AN equal in length to EH,and draw the lines OR and NP at right angles to NB andNA ; also, the lines RD and PC at right angles to RO andPN. Edges to be allowed. 46 TIN, SHEET-IRON AND COPPEE-PLATL nORKER. … Fig. 56.OCTAGON. To describe a Pattern for Tapering Octagon Top or Cover.—Erect the perpendicular line GE (Fig. 57); draw theline AB at right angle to GE ; make FE equal to the slantheigi-t of the article, and draw the line CD parallel to AB;make AB equal in length to one of the longest sides ofthe…
