Perspective and geometrical drawing : adapted to the use of candidates for second and third-class teachers' certificates (1887)
McGuirl, Thos. H. (Thomas H.) · Toronto, Ont. : W. Briggs · leaf 29
fig. 13 draw H.L., B.L. and L.D., and find LMP,take B 2 to left and A 4 to left of B, also S 4 to right ofB. Erect AC and BD perpendiculars to AB, and each 4 inheight; join CD, C C.Y., D C.V., B C.V., and S LMP. LetS LMP cut B C.V in G; draw GF parallel to BD, and FE3 26 DRAWING. parallel to CD :… … THE LINE. 27 Exercise III. (H = 6, L.D. = 4, scale { = !.) 1. Draw a line -1 in length on G.P., parallel to P.P. and 4within it, directly in front. 2. Draw a line 4 in length parallel to G.P. and 4 above it,touching P.P. 4 to left, and perpendicular to it. 3. Draw a line 3 in length perpendicular…
Geometrical drawing · Perspective
