30 DRAWING. To represent a square perpendicular to G.P. and P.P. Let H.L. and B.L. be drawn, also L.D., and find X, Take … any points A, B, C on B.L. at equal distances, and at eacherect a perpendicular equal to AB or CD; join EH, which THE SQUARE. 31 will .be parallel to AD; join A C.Y., B C.Y., C C.V. andJ) C.Y. Take a point a at a distance from A equal to AB(on left), and join AX to cut A C.Y. in K; draw KN…
